Orbital Welding System
TP060 Most Productive Welding Head
Vadodara, GJ
Storefront →Price on request
MOQ — Lead time on requestCurrency INR
Customization for this product
This welding head is a specially designed TIG welding head for small tube to tube-sheet, suitable for carbon steel, stainless steel, mainly for protruded tube, flush tube and indented tube connection with or without wire feeding. It can weld high protection requirement material such as titanium alloy with tow cover. Support equipment: i-Arc400 Programmable Orbital Welding Power Source. Application: chemical, food, medicine, heat exchanger, power plant, military facility, nuclear facility and so on. High-precision positioner, fast and accurate, suitable for small heat exchanger. Auto AVC controlling on or off for manually adjusting. Water cooled TIG welding head, convenient to change or adjust tungsten. Integrated wire feeding, 1.0KG wire plate. No-wire-twist design and special wire feeding design to meet complex single or multi-layer welding requirements. Buttons on handle, convenient to operate.
BharatSeal order protection
Secure payments
Every payment is processed via Razorpay with PCI-DSS data protection and SSL encryption. We never see your card details.
PayUPIVisaMCAmexRuPayNet BankingWalletsPay Later+ more
Money-back protection
Claim a refund if your order doesn't ship, arrives damaged, or doesn't match the agreed spec. Disputes resolved within 7 working days.
Trade Assurance — not yet enrolled by this seller
This seller has not yet activated Trade Assurance. Pay outside BharatSeal at your own risk — we recommend chatting first to verify.
Only orders placed and paid through BharatSeal can enjoy free protection by 🛡 BharatSeal Trade Assurance.
Highlights at a glance
- ✓Category: Orbital Welding System
- ✓Made in Vadodara, GJ, India
ProductsOrbital Welding System
Tube-Tube Sheet Welding
Applications
Pressure Vessel Orbital Application
Petrochemical Heat Exchanger
Boiler Heat Exchanger
Features
- High-precision positioner, fast and accurate, suitable for small heat exchanger
- Auto AVC controlling on or off for manually adjusting
- Water cooled TIG welding head, convenient to change or adjust tungsten
- Integrated wire feeding, 1.0KG wire plate.
- No-wire-twist design and special wire feeding design to meet complex single or multi-layer welding requirements
- Buttons on handle, convenient to operate.
Specification
Material | Carbon steel, stainless steel, titanium alloy(with cover)
Tube OD(mm) | Φ8～Φ32(3/8″～1 1/4″)
Connection | Retract tube, protrusion tube, flush tube
Rotation Speed(rpm) | 0.37～7.39
Arc Adjusting Distance(mm) | 18
Max Wire Feeding Speed(mm) | 1800
Wire Diameter(mm) | Φ0.8
Protective Gas | Ar
Cooling | Water
Cooling flow(ml/min) | ≥600
Duty cycle | 300A 60%
Weight(kg) | 11(no cable)
Dimension (mm) | 550×290×510
