Perforated Type

Structure with a solid or perforated bottom with integrated side rails. Our standard FRP channel type trays include – perforated type, solid bottom, pre-drilled cable tray – which are designed for light loads namely instrumentation and control cables and for the transition from cable trays to individuals control points. Perforated Type Size Chart: (All dimensions are in mm.) Width(W) Height(H) Thickness(T) 300 50 5 250 50 5 200 50 4 150 50 5 150 50 4 100 50 6 100 50 4 100 40 4 100 30 6 Width(W) Height(H) Thickness(T) 100 30 5 100 30 4 100 30 3 75 50 4 75 30 4 75 25 3 60 30 5 60 30 3 50 50 4
