WELDEX-SS

Name: WELDEX-SS
Brand: WELDEX
SKU: WELDEX-SS
Availability: MadeToOrder

Certificates:ISO 9001

TIRUPATI ELECTRODES PRIVATE LIMITEDKolkata, WB

Storefront →

Brand WELDEXSKU WELDEX-SS

Price on request

MOQ 0 0 daysCurrency INR

Estimated delivery by 7 Jul 2026

BharatSeal order protection

Secure payments

Every payment is processed via Razorpay with PCI-DSS data protection and SSL encryption. We never see your card details.

PayUPIVisaMCAmexRuPayNet BankingWalletsPay Later+ more

Money-back protection

Claim a refund if your order doesn't ship, arrives damaged, or doesn't match the agreed spec. Disputes resolved within 7 working days.

Trade Assurance — not yet enrolled by this seller

This seller has not yet activated Trade Assurance. Pay outside BharatSeal at your own risk — we recommend chatting first to verify.

Only orders placed and paid through BharatSeal can enjoy free protection by 🛡 BharatSeal Trade Assurance.

Service

0-day production

Standard lead time once order is confirmed.

Highlights at a glance

✓Brand: WELDEX
✓Category: Mild Steel Electrodes
✓Made in Kolkata, WB, India
✓Certified: ISO 9001

About this item

Ultimate Tensile Strength 501.0 N/mm²
Yield Strength 403.0 N/mm
Elongation (GL=5d) 26%
Reduction in Area 68.20%

Description

A Heavy Coated, Rutile Type Electrode for Radiographic Quality Welds, Suitable for Pressure Vessels, Boilers, Storage Tanks, Girder Fabrication L.P.G. Cylinders Etc.

Description

A Heavy Coated, Rutile Type Electrode for Radiographic Quality Welds, Suitable for Pressure Vessels, Boilers, Storage Tanks, Girder Fabrication L.P.G. Cylinders Etc.

Mechanical Properties

Ultimate Tensile Strength
**501.0 N/mm²**
Yield Strength
**403.0 N/mm**
Elongation
**(GL=5d) 26%**
Reduction in Area
**68.20%**

Weld Metal Chemical Composition (%)

C | MN | SI | S | P |
| --- | --- | --- | --- | --- |
| 0.085 | 0.55 | 0.21 | 0.020 | 0.025 |

Welding Parameters

Size(mm) | 2.50 x 350 | 3.15 x 350 | 4.00 x 350 | 5.00 x 350 |
Current(Amp.) | 60-90 | 90-130 | 130-170 | 170-210 |

Packing Data

Ø x L, MM | Pcs / Pkt | Pkt / Box | Pcs / Box | Net Wt / Box (Kg) |
| --- | --- | --- | --- | --- |
| 2.50 X 350 | 290 | 12 | 3480 | 20 |
| 3.15 X 350 | 85 | 12 | 1020 | 20 |
| 4.00 X 450 | 55 | 12 | 660 | 20 |

Key attributes

Category	Mild Steel Electrodes
Brand	WELDEX
Model number	WELDEX-SS
Place of origin	Kolkata, WB, India
Minimum order	0 units
Lead time	0 days
Dimensions	350 × 0 × 0 mm
Weight	0 kg
