Mild Steel Electrodes
WELDEX - 6013
Brand WELDEXSKU WELDEX-6013
Price on request
MOQ 0 0 daysCurrency INR
Estimated delivery by 13 May 2026
Service
0-day production
Standard lead time once order is confirmed.
Highlights at a glance
- ✓Brand: WELDEX
- ✓Category: Mild Steel Electrodes
- ✓Made in Kolkata, WB, India
- ✓Certified: ISO 9001
About this item
- Ultimate Tensile Strength 410-540 N/mm²
- Yield Strength 360-440 N/mm²
- Elongation (GL=5d) 22-26%
- Impact (CVN) at 0° C 50-80 Joules avg
Description
A Medium Coated, Rutile Type, Normal Penetration, All Position M.S. Electrode, Suitable Construction Work, Storage Tanks, Construction Machinery, Rail Coaches, Wagon, General Repairs & Maintenance
Description
A Medium Coated, Rutile Type, Normal Penetration, All Position M.S. Electrode, Suitable Construction Work, Storage Tanks, Construction Machinery, Rail Coaches, Wagon, General Repairs & Maintenance
Mechanical Properties
Ultimate Tensile Strength
**410-540 N/mm²**
Yield Strength
**360-440 N/mm²**
Elongation
**(GL=5d) 22-26%**
Impact
**(CVN) at 0° C 50-80 Joules avg**
Weld Metal Chemical Composition (%)
C | MN | SI | S | P |
| --- | --- | --- | --- | --- |
| 0.06 - 0.10 | 0.35 - 0.60 | 0.20 - 0.28 | 0.030 | 0.030 Max |
Welding Parameters
Size(mm) | 2.50 x 350 | 3.15 x 350 | 4.00 x 350 | 5.00 x 350 |
Current(Amp.) | 60-90 | 90-130 | 140-180 | 180-230 |
Packing Data
Ø x L, MM | Pcs / Pkt | Pkt / Box | Pcs / Box | Net Wt / Box (Kg) |
| --- | --- | --- | --- | --- |
| 2.50 X 350 | 125 | 12 | 1500 | 28 |
| 3.15 X 350 | 90 | 12 | 1080 | 30 |
| 4.00 X 450 | 60 | 12 | 720 | 42 |
Key attributes
Packaging & delivery
Certificates
ISO 9001
