DUAL BANK BATTERY CHARGER

Name: DUAL BANK BATTERY CHARGER
Brand: EPSILON ELECTRONIC EQUIPMENT AND COMPONENTS PRIVATE LIMITED
Availability: MadeToOrder

Certificates:ISO 9001:2008ISO 9001:2015

EPSILON ELECTRONIC EQUIPMENT AND COMPONENTS PRIVATE LIMITEDKushaiguda Hyderabad, TG

Storefront →

Price on request

MOQ — Lead time on requestCurrency INR

BharatSeal order protection

Secure payments

Every payment is processed via Razorpay with PCI-DSS data protection and SSL encryption. We never see your card details.

PayUPIVisaMCAmexRuPayNet BankingWalletsPay Later+ more

Money-back protection

Claim a refund if your order doesn't ship, arrives damaged, or doesn't match the agreed spec. Disputes resolved within 7 working days.

Trade Assurance — not yet enrolled by this seller

This seller has not yet activated Trade Assurance. Pay outside BharatSeal at your own risk — we recommend chatting first to verify.

Only orders placed and paid through BharatSeal can enjoy free protection by 🛡 BharatSeal Trade Assurance.

Highlights at a glance

✓Category: Signalling Equipment
✓Made in Kushaiguda Hyderabad, TG, India
✓Certified: ISO 9001:2008, ISO 9001:2015

About this item

Reliable Battery Charging Equipment with interlocked design.
Internal isolation between charging and discharging banks for safety.
Charges one set of batteries while another powers the load.
Designed for continuous operation at rated voltage and current (0-55º C ambient).
Includes overload and short circuit protection.
Housed in a durable 1 mm thick MS Box with electrostatic epoxy powder coating.

Description

The Dual Bank Battery Charger is a Reliable Battery Charging Equipment and is of interlocked type with internal isolation available between the charging and discharging banks. It shall charge one set of batteries, while the other set of batteries is connected with the load for operating the block circuit. Subsequently, the designed set of batteries shall be put on charge by connecting it to the charger, while the charged set of batteries shall be connected to the load through a switch provided on the charger. The charger is designed for continuous operation at rated voltage and current at ambient temperature 0-55º C. The unit has over load and short circuit protection. The entire system is housed in an MS Box of 1 mm thickness and has electrostatic epoxy powder coating. The Charger is housed in an MS Box of 1 mm thickness, with slots for ventilation and is covered with a wire mesh.
